• Model NO.：KM-20201111
• Surface Treatment：Polished
• Size：1,2"-60"
• Thickness：1~30mm
• Process Way：Cold Drawn,Cold Pilgered
• Length：3~12 Meters
• Product Packing：in Bundle or Seaworthy Wooden Cases
• Delivery Condition：Annealed and Pickled
• Transport Package：in Bundles ,Wooden Boxes or Customers′request
• Specification：ASTM A312,A213,A269,A270, EN10216, DIN17455, etc
• Trademark：KINGMETAL
• Origin：China
• HS Code：73044190
• Production Capacity：600 Tons,Month

Size:1/2" to 60" (DN15 ~DN1500), outer diameter up to 1500mm         Rate:SCH5S to SCHXXS         Standard:

ASTM A312, A213, A268,A269, A249, A270, A376,A511;
ASTM A789, A790;
ASTM B163, B165, B167, B407, B423, B444, B622, B677, B729;
EN10216-5, EN/DIN17455,EN/DIN17456, EN/DIN17458DIN2462 etc.

         Material:

Stainless: TP304,304L,304H,316,316L,316H,316Ti,317,317L,309S,310S,310H,347,347H,321,321H, 904L, S31254
(mat.1.4301,1.4307,1.4948,1.4401,1.4404,1.4571,1.4438,1.4438, 1.4833,1.4841,1.4845,1.4845,1.4450,1.4541,1.4878,1.4539, 1.4547/254SMO) etc.



Duplex: UNS S31803 , S32205, S32750,S32760,S32304 (Mat.1.4462,1.4410,1.4501,1.4362)etc.



Alloy: Monel 400, Inconel 600, Inconel 625, Incoloy 800, Incoloy 800H, Incoloy 825, Hastelloy B2, Hastelloy C-22, Hastelloy C-276, 15-5PH, 17-7PH,Cu70Ni30(C71500/B30), Cu90Ni10(C70600/B10)etc.

          C(max)Si(max)Mn(max)P(max)S(max)CrNiMoTiTP304/1.43010.0801.002.000.0450.03018.0-20.08.0-10.5  TP304L/1.43070.0351.002.000.0450.03018.0-20.08.0-12.0  TP304H/1.49480.04-0.101.002.000.0450.03018.0-20.08.0-12.0  TP316/1.44010.0801.002.000.0450.03016.0-18.011.0-14.02.0-3.0 TP316L/1.44040.0351.002.000.0450.03016.0-18.010.0-14.02.0-3.0 TP316Ti/1.45710.0801.002.000.0450.03016.0-18.010.0-14.02.0-3.00.7>5x(C+N)TP321/1.45410.0801.002.000.0450.03017.0-19.09.0-12.0 0.7>5x(C+N)TP317L/1.44490.0801.002.000.0450.03018.0-20.011.0-14.03.0-4.0 TP347H/1.49120.04-0.101.002.000.0450.03017.0-19.09.0-13.0  TP309S/1.48330.0801.002.000.0450.03022.0-24.012.0-15.00.75 TP310S/1.48450.0801.002.000.0450.03024.0-26.019.0-22.00.75

Material Grade:

American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H,  TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

Russia Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ




Application:

• Food processing equipment, particularly in beer brewing, milk processing & wine making.
• Kitchen benches, sinks, troughs, equipment and appliances
• Architectural panelling, railings & trim
• Chemical containers, including for transport
• Heat Exchangers
• Woven or welded screens for mining, quarrying & water filtration
• Threaded fasteners
• Springs
• Others
•
