• Model NO.：KM-02
• Bending Angle：15o 30o 45o 60o 90o 135o180o,
• Steel Grade：Q235, 20#, 10#, Q345 A234 Wpb, Wp5, Wp9,Wp11,
• Production Standard：ASTM A234, ASME B16.9, JIS B2311, DIN 2605
• Custom Code：730793, 730792
• Transport Package：in Wooden Case
• Specification：ASTM, DIN, JIS, BS, EN
• Trademark：Kingmetal
• Origin：Made in China
• HS Code：730793
• Production Capacity：3000ton,Month

Product Detailes:O.D.Seamless: From 1/2" up to 24" DN15-DN600
Welded: From 26" up to 80" DN650-DN2000 W.T.Sch10, Sch20, Sch30, Sch40, STD, Sch80, XS, Sch120, Sch160, XXS Bending Radius (R)R=3D 4D 5D 6D 7D 8D 9D 10D. Bending angle (θ )15o 30o 45o 60o 90o 135o180o, and also could manufacture according to
the angles given by the clients. Straight Length (L)The length between two ends general from 300mm-1500mm,
and also can produce according to the clients' requirement to product. MaterialA234-WPB, A420-WPl6, A234-WP11, A234-WP5,
A403-WP304, A403-WP304L, A403-WP316, A403-WP316L, SS304, SS304L, SS316, SS316L Application StandardASTM B16.9, ASTM B16.11, ASTM B16.28, JIS B2311/2220, DIN2617/2616/2615/2391FormingHot formed, cold drawnTypeSeamless and Welded, LR & SREndBevel, plain, thread, socket Surface Treatment1) Sandblasting
2) Paint black lacquer or transparent oil on surface to prevent corrosion ApplicationPetroleum industry, refinery company, fertilizer industry, power station, shipbuilding, onshore platform. Packing1) Seaworthy wooden box for fittings with size from 1/2" ~ 14"
2) Seaworthy wooden pallet for fittings with size above 14"
3) According to the packing requirement of clients WeightWeight (kg)=[0.0433(d-t)trθ ]/100000+l(the weight of two ends straight bend)MOQ10 pieceDelivery TermFOB(30% down payment in advance, the balance before shipment)

CIF or C&F(30% in advance , the balance against with the copy of B/L)Delivery time15~30 days after receipt of advanced payment
