Q235B S235 ERW Welded Steel Pipe by API ASTM DIN Standard
Qingdao Ironsteel International Trading Co., Ltd.- Type：Welded
- Technique：ERW
- Material：Carbon Steel
- Surface Treatment：Bare Pipe, Black Pipe, 3lpe Coating, Fbecoating
- Usage：Pipeline Transport, Oil,Gas Drilling, Chemical Industry, Construction & Decoration
- Section Shape：Round
Base Info
- Model NO.：Q235B welded steel pipe
- Outer Diameter：21mm~660mm
- Wall Thickness：2mm~20mm
- Length：6~9 Meters
- Standard：ASTM A53, API 5L, En10219, GB,T
- Transport Package：Standard Seaworthy Packing
- Specification：full range of size
- Trademark：Iron&steel
- Origin：China
- HS Code：73061900
- Production Capacity：2000tons Per Month
Description
N.D.O.D W.T. WEIGHT SCH TEST PRESSURE NO.of THREADS PER INCH PLAIN ENDS kg/m kg/ft Grade A Grade B in in mm in mm blk gal blk gal psi kg/cm2 psi kg/cm2 1/2 0.840 21.3 0.109 2.77 1.27 1.35 0.39 0.41 40 700 50 700 50 14 3/4 1.050 26.7 0.113 2.87 1.69 1.79 0.52 0.55 40 700 50 700 50 14 1 1.315 33.4 0.133 3.38 2.50 2.65 0.76 0.81 40 700 50 700 50 11-1/2 1-1/4 1.660 42.2 0.140 3.56 3.39 3.59 1.03 1.10 40 1200 84 1300 91 11-1/2 1-1/2 1.900 48.3 0.145 3.68 4.05 4.29 1.23 1.31 40 1200 84 1300 91 11-1/2 2 2.375 60.3 0.154 3.91 5.44 5.77 1.66 1.76 40 2300 162 2500 176 11-1/2 2-1/2 2.875 73.0 0.203 5.16 8.63 9.15 2.63 2.79 40 2500 176 2500 176 8 3 3.500 88.9 0.125 3.18 6.72 7.12 2.05 2.17 --- 1290 91 1500 105 8 0.156 3.96 8.29 8.79 2.53 2.68 --- 1600 112 1870 131 0.188 4.78 9.92 10.52 3.02 3.21 --- 1930 136 2260 159 0.216 5.49 11.29 11.97 3.44 3.65 40 2220 156 2500 176 3-1/2 4.000 101.6 0.125 3.18 7.72 8.18 2.35 2.49 --- 1120 79 1310 92 8 0.156 3.96 9.53 10.10 2.90 3.08 --- 1400 98 1640 115 0.188 4.78 11.41 12.09 3.48 3.69 --- 1690 119 1970 139 0.226 5.74 13.57 14.38 4.14 4.38 40 2030 143 2370 167 4 4.500 114.3 0.125 3.18 8.71 9.23 2.65 2.81 --- 1000 70 1170 82 8 0.156 3.96 10.78 11.43 3.29 3.48 --- 1250 88 1460 103 0.188 4.78 12.91 13.68 3.93 4.17 --- 1500 105 1750 123 0.237 6.02 16.07 17.03 4.90 5.19 40 1900 134 2210 155 5 5.563 141.3 0.156 3.96 13.41 14.21 4.09 4.33 --- 1010 71 1180 83 8 0.188 4.78 16.09 17.06 4.90 5.20 --- 1220 86 1420 100 0.219 5.56 18.61 19.73 5.67 .01 --- 1420 100 1650 116 0.258 6.55 21.77 23.08 6.64 7.03 40 1670 117 1950 137 6 6.625 168.3 0.188 4.78 19.27 20.43 5.87 6.23 --- 1020 72 1190 84 8 0.219 5.56 22.31 23.65 6.80 7.21 --- 1190 84 1390 98 0.250 6.35 25.36 26.88 7.73 8.19 --- 1360 96 1580 111 0.280 7.11 28.26 29.96 8.61 9.13 40 1520 107 1780 125 8 8.625 219.1 0.188 4.78 25.26 26.78 7.70 8.16 --- 780 55 920 65 --- 0.203 5.16 27.22 28.85 8.30 8.79 --- 850 60 1000 70 0.219 5.56 29.28 31.04 8.92 9.46 --- 910 64 1070 75 0.322 8.18 42.55 45.10 12.97 13.75 40 1340 94 1570 110
