JIS G4503 Scm415 Seamless Alloy Steel Pipe.
Guangzhou Kingmetal Steel Industry Co., Ltd.- Type：Seamless
- Technique：Hot Rolled
- Material：Alloy Steel
- Surface Treatment：Antiseptical
- Usage：Pipeline Transport, Machinery Industry, Chemical Industry, Mining, Special Purpose
- Section Shape：Round
Base Info
- Model NO.：KM-98
- Outer Dimensions：19.05mm~114.3mm
- Wall Thickness：2.0mm ~14 mm
- Length：Max 16000mm
- Delivery Time：30-45 Days Ex Mill
- Loading Port：Chinese Main Port
- Certificate：ISO API
- Type of End：Plain End, Beveled Edge
- Process Method：Cold Rolled, Hot Rolled
- MOQ：5 Tons
- Testing Way：The Third Party Test
- Transport Package：in Bundle or Customer′s Requirement
- Specification：ISO TUV PED API
- Trademark：KINGMETAL
- Origin：Made-in-China
- HS Code：730491000
- Production Capacity：2000 Tons Per Month
Description
Seamless Alloy Steel PipeOD x WT: 42-720(mm) x 4-120(mm) Grade: As requst Standard: ASTM, ASME, EN, JIN, DIN Type of End: Plain End, Beveled Edge Applications: As list
Commodity
Alloy Steel Pipe/Tube
Standard
GB5310-2008,GB9948-2006,ASTM A335/A335M,ASTM A213/A213M,DIN17175-1979,JISG3467-1988,JISG3458-1988
Material
10#-45#,20MnG,25MnG,15CrMoG,35CrMo,16Mn,etc
Production Process
Cold drawn/hot rolled
Surface Finish
2) Anti-corrosion and high-temperature resistant with black painting
OD(mm)
21-1030mm
Thickness(mm)
2-35mm
OD Tollerance
D≤48.3mm,±0.4mm/-0.79mm,D48.3-114.3mm,±0.79%,D114.3mm±1.59/-0.79mm
WT Tollerance
WT±12.5%
Chemical Elements
C0.3%,Si≥0.1%,Mn:29-1.06%,P≤0.035%,S≤0.035%,Cu<0.4%,Cr<0.4%,Cr<0.4%,Mo:0.15%,V:0.08%
Tenslle Strength
415MPA
Yield Point
240MPA
Length(m)
5.8m,6m,11.8m,12m, or as customers' request
Ends
Beveled or square cut plastic caped
Packing
Standard export sea-worthy package, or as customers' request
Delivery Time
Within 5-35 working days
Quality
High quality
Productivity
500MT
MOQ
10MT
Application
Alloy steel pipe applies to petroleum, chemical industry, electric power, boiler, high temperature resistant, low temperature resistant, corrosion resistant steamless steel pipe used. Our company has cooperative relation between the domestic agents.
Others
1) Special design available according to requirement
2) Anti-corrosion and high-temperature resistant with black painting
Note
The quality of the products is something we never neglect. Good quality can ensure continued sales. Our company has carried out effective quality assurance and long-term plan to improve products quality. Fasten delivery. Quality assured.
