En 10297-1 Grade 38mn6 Carbon Steel Seamless Tubes
Guangzhou Kingmetal Steel Industry Co., Ltd.- Type：Seamless
- Technique：Hot Rolled
- Material：Alloy Steel
- Surface Treatment：Oiled
- Usage：Machinery Industry
- Section Shape：Round
Base Info
- Model NO.：WAN432
- Length：5.8-11.8
- Size：1,2"-8"
- Name：P355n Steel Pipe
- Keyword：P335n Steel, P460n Steel Properties, P
- Steel Grade：P275,P355,P460n Nh Nl1 Nl2
- Transport Package：Bundles with Steel Strips and Wooden Frame
- Specification：1,8"-2"
- Trademark：KINGMETAL
- Origin：China
- HS Code：73060000
- Production Capacity：1000tons,Month
Description
Yield StrengthTensile Strength Elongation A5 min MPa min ksi min MPa min MPa min ksi min Percentage 670 - - 14
EN 10297-1 Grade 38Mn6 specification covers Alloy fine grain steel, pressure purposes. Pipe will be supplied in 5-7 metre random lengths with butt-weld ends and varnished to avoid oxidation of the steel when in storage. All pipes are fully certified and traceable with heat numbers hard stamped onto each random length. KINGMETAL Pipe can supply cut lengths; long pieces and even bore from forged, machined bar to satisfy your urgent demand.
More seamless steel pipe grade and standard we can offer :
what we do?
KINGMETAL STEEL INDUSTRY CO.,LTD ,is a professional company in manufacturing and saling steel pipes and pipe fittings ( tee, elbow ,reducer ,flanges). we are an old company in this area ,we start from 1989 and have rich exporting experience
Cooperating with us you will feel easy and safe !
| Equivalent Designation |
| DIN | EN | BS | NFA | ASTM | ASME |
| - | EN 10297-1 Grade 38Mn6 | - | - | - | - |
KINGMETAL is considered as the most Reliable EN 10297-1 Grade 38Mn6 Tubes Supplier from China.
Dimensional Tolerances of EN 10297-1 Grade 38Mn6 OD/Wall tolerance
| Execution | Size Range | OD Tolerance | Wall tolerance |
| Hot-rolled Tube | OD - 80 mmOD > 80 mmWall < 12 mmWall - 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall - 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 - 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 - 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
| Standard | steel grade | standard name | Diemension Range |
| EN 10208 | L210GA,L235GA,L245GA,L290GA,L360GA, L245GA,L290NB,L260NB,L415NB,L360QNB, LI150QB,L450QB,L485QB,L555QB | Steel pipe fir pipelines for cumbustible Fluids | 33.7-914mm |
| EN10210 | S235JRH,S275JOH,S275J2H,S355JOH, S355J2H,S355K2H,S375NH,S25NLH, S355NH,S355NLH,S420NH,S420NLH, S461NH,S460NLH | Hot finished ,structural hollow sections of Non-alloy and tube Grain steels | 10.2-711mm |
| EN10216-1 | P195TRI,T195TR2,P235TR1,P235TR2, P265TRI,P265TR2 | seamless steel tubes for pressure purpose 1 : Non-alloy steel | 10.2-711mm |
| EN10216-2 | P195GH, P235GH, P265GH, 20MnNb6,16Mo3, 8MoB5-4, 14Mov6.3, 10CrMo5.5, 13CrMo4-5, 10CrMo9-10, 11Cr9.10, 15NiCuMoNB-6-4, X11CrMo5+1, X11CrMo5+NTI, X11CrMo5+NT2, X11CrMo9.1+1, X11CrMo9.1+NT, X10CrMoVNb9-1, X20CrNiV11-1 | seamless steel tubes for pressure purpose 2 : Non-alloy steel and alloy steel ,Tubes with specified elevated Temperature Properties | 10.2-711mm |
| EN10216-3 | P275NL1,P275NL2,P355N,P355BH,P355NL, P355NL2,P460N,P460NH,P460NL1,P460NL2, P620Q,P620QH,P690Q,P690QH,P690QL1, P690QL2 | seamless steel tubes for pressure purpose 3 : alloy fine Grant stee Tubes | 10.2-711mm |
