• Model NO.：Dingang
• Thickness：0.16-1.5mm
• Transport Package：Standard Export Packing
• Specification：1060
• Trademark：OEM
• Origin：China
• HS Code：76061251
• Production Capacity：3, 000, 000 Tons Per Year

Basic Info.

Model NO. Dingang Thickness 0.16-1.5mm Transport Package Standard Export Packing Specification 1060 Trademark OEM Origin China HS Code 76061251 Production Capacity 3, 000, 000 Tons Per Year

Product Description

Color coated aluminum coil details:
The types of Pre painted aluminum coil: PVDF(mainly), PE and ACRYLIC

Color coated aluminum coil details:

1) The types of Pre painted aluminum coil: PVDF(mainly), PE and ACRYLIC

2) Thickness of total coating: PVDF: More then 25 micron; PE, more then 18 micron.

3) Paint: PPG or Nippon.

4) Interior diameter: 505mm

5) Width of Pre painted aluminum coil: From 30mm-1500mm, sheets are also available

6) Color: Panton, RAL or refer to customers' counter sample.

7) Coating hardness: (pencil hardness) more than 2H

8) Impact resistance: No cracking and peeling(50kg/cm, ASTMD-2794: 1993)

9) Flexibility(T-bend): No more than 2T

10) MEK resistance: More than 100

The base of Pre painted aluminum coil details:
1) Temper of Pre painted aluminum coil: H14, H18, H24 mainly

2) Alloy of Pre painted aluminum coil: 1100, 1050, 1060, 3003, 3105, 3005

3) Origin: China

4) Minimum order quantity of Pre painted aluminum coil: 5 tons each size

5) Lead Time of Pre painted aluminum coil: Within 20 days

6) The term of payment of Pre painted aluminum coil: T/T, irrevocable L/C at sight

7) Application of Pre painted aluminum coil: Lighting, printing, packing, decorative, electronics surface, hot rolled thick plate, PS base plate, aluminum plastic base plate, aluminum curtain wall base plate, aluminum composite panel base plate, aluminum spacer, aluminum embossed sheet, aluminum tread plate

8) Remarks of Pre painted aluminum coil: Specific requirement of alloy, temper or specification can be discussed at your request.
