Ungalvanized 6*7 FC Wire Rope Sand Line
Chongqing Geyo Machinery Co., Ltd.- Certification：ISO, CE, ISO, CE, TUV
- Surface：Galvanized,Ungalvanized,Stainless Steel, Smooth
- Technique：Galvanized, Ungalvanized
- Application：Rope, Packaging, Netting, Manufacturing, Fencing, Rope, Construction
- Alloy or Not：Non-alloy, Non-Alloy
- Standard：BS, JIS, GB, ASTM, DIN, AISI, BS, JIS, GB, ASTM, DIN, AISI
Base Info
- Model NO.：6*7
- Structure：6*7 FC
- Tensile Strength：1570-1960MPa
- Diameter：as Customer′s Request
- Steel Grade：High Carbon Wire Rod
- Delivery Time：15 Days
- Transport Package：in Wooden Reel
- Specification：0.2-52mm
- Trademark：GEYO
- Origin：China
- HS Code：7312100000
- Production Capacity：10000meters,Month
Description
Basic Info.
Model NO. 6*7 Structure 6*7 FC Tensile Strength 1570-1960MPa Diameter as Customer′s Request Steel Grade High Carbon Wire Rod Delivery Time 15 Days Transport Package in Wooden Reel Specification 0.2-52mm Trademark GEYO Origin China HS Code 7312100000 Production Capacity 10000meters/MonthProduct Description
Ungalvanized 6*7 FC wire rope sand lineFeatures
1.Excellent Abrasion Resistance, Very Durable
2.Used with Oil Well Drilling
3.Drill Line for Cable Drilling Rigs and Rotary Drill Rigs
Brief Description
1.The fiber core 6 x 7 construction features larger wires than many other wire rope classes.
2.Offers excellent resistance to abrasion, resistant to kinking; spools evenly.
3.Ideal for sand and swabbing lines, so it's also sometimes referred to as sand line wire rope.
Specification
| Diameter | Steel Grade | Core | Class | Material | Quantity | Weight | Break Strength |
| 5/16" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.15lbs | 8200lbs |
| 3/8" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.21 lbs | 11720lbs |
| 7/16" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.29lbs | 15680lbs |
| 1/2" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.38lbs | 20600lbs |
| 9/16" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.48lbs | 26000lbs |
| 5/8" | Extra Improved Plowed Steel (EIPS) | Fiber | 6x7 | Bright Steel | Ordered in lineal feet | 0.59lbs | 31800lbs |
Commonly used in oil, gas and water drilling industries, the 6 x7 wire rope is also known as a sand line. It's typically operated and stored on a winch drum and is capable of tensile forces higher than electric wire line or slick line. A fiber core (generally made of vegetable such as sisal, etc., or a synthetic like polypropylene, etc.) gives this steel rope cable excellent resistance to fatigue caused from excessive bending. Spools evenly and resists kinking. Common uses: coring lines, sand lines, trawl cables, swabbing lines.
PRODUCTION
PRODUCTION FLOW AND MEASURING METHOD OF WIRE ROPE
STORAGE
TRANSPORTATION OR LOADING
For enquiry,please kindly advise below information to us.
1.Application: For which rope will be used.
2.Size: Diameter of the rope in millimeter or inches.
3.Construction: Number of strands, number of wires per strand and type of strand construction.
4.Type of Core: Fiber core(FC), independent wire rope core(IWRC) or independent wire strand core(IWSC).
5.Lay: Right regular lay,left regular lay,right lang lay,left lang lay.
6.Lubrication:Preformed or not.
7.Material: Bright(un-galvanized),galvanized or stainless steel
8.Grade of wire: Tensile strength of wires
9.Breaking Load: Minium or calculated breaking load in tones or pounds.
10.Length: Length of wire rope.
11.Packing: In coils wrapped with oil paper and hessian(orp.p)cloth, or on wooden reels.
12.Quantity: By number of coils or reels,by length or weight
13.Specification: Any recognized specification, if necessary.
14.Certification: Mill sheet and/or a third party's inspection,if necessary.
15.Remarks: Shipping marks and any other special requirements.
