N04400 Monel 400 Ni Cu Alloy Pipe

Shanghai Bozhong Metal Group Co., Ltd.
  • Type：Monel 400
  • Standard：ASTM, AISI, GB, JIS, DIN, EN
  • Grade：Monel 400
  • Certification：ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
  • Shape：Round
  • Technique：Hot Rolled

Base Info

  • Model NO.：Monel 400
  • Surface Treatment：Black,Polish,Black
  • Sample：N04400 Monel 400 Ni Cu Alloy Pipe
  • Custom Sample：5-7 Days
  • Certificate：ISO
  • Shipping Port：Shanghai
  • MOQ：500kg
  • Transport Package：Good Quality & Fumigated Wooden Box
  • Specification：Dia 16 25 30 40mm * 6000mm length
  • Trademark：Tisco,Baosteel
  • Origin：China
  • HS Code：7222300000
  • Production Capacity：600 Metric Ton ,Month

Description

Element

Content

Ni63 % min

Cu

28 - 34 %

Fe

2.5 % max

Mn

2 % max

Typical Properties of Monel 400

Typical properties

Heat Treatment (After Forming)

Annealed/Spring Temper

Stress relieve at 300-320°C (570-610°F) for 1 hour and air cool.

Condition

Approx Tensile Strength

Approx Service Temp.

Annealed

400 - 600 N/mm2

58 - 87 ksi

-200 to +230°C

-330 to +445°F

Spring Temper

850 - 1050 N/mm2

123 - 152 ksi

-200 to +230°C

-330 to +445°F

R

Polished Bar(circle,Square)

Solution annealing,descaling

Forged barΦ26-245mm,Length≤4000mm

Weld tube

Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm

Base on your requirement

Use for PHE

Seamless Tube

Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm

Base on your requirement

Use for PHE

Wire

Outer diameterΦ0.1-13mm

Base on your requirement

Ni & Ni alloy, Ti & Ti alloy

Forged piece

roundness and square alloy

Base on your requirement

Steel, Alloy

Flangs

All kinds of Flangs

Base on your requirement

Steel, Alloy

Welding Material

Coil wire Φ0.90mm/1.2mm/1.6mm

Base on your requirement

Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France.

Straight WireΦ1.2mm/1.6mm/2.4mm/3.2mm/4.0mm

Welding rodΦ2.4mm/3.2mm/4.0mm

Tube

Elbow, three links, four links, different diameter size

Base on your requirement

Ni & Ni alloy, Ti & Ti alloy

Explosive bonded laminate

Raw Sheet Thickness≥2mm

Base on your requirement

Ni & Ni alloy, Ti & Ti alloy
