1.4845 S31008 Ss 310S Stainless Steel Bars and Rods Round Bar

Wuxi City Ge Ming Sheng Steel Trading Co., Ltd
  • Type：Stainless Steel Bars
  • Standard：ASTM
  • Grade：300 Series
  • Certification：AISI
  • Shape：Round
  • Technique：Cold Rolled

Base Info

  • Model NO.：310S
  • Surface Treatment：Bright
  • Transport Package：Wooden Box
  • Specification：OD 6-630mm
  • Production Capacity：50000kgs

Description

Product NameCold Drawn Stainless Steel Round BarGrade310S 314 310 StandardASTM JIS DINDiameter4.7 - 100mmLength2000mm~6500mm or cut to any length as your requestShapeRound SectionSurfacecold drawn etcPlace Of OriginChina (Mainland)Other grade availableMainly in grade 201 301 303 309S 310S 316L 317L 321 410 420 440A/B/C 2205 2507 904L 17-4ph 17-7ph 15-5ph

Chemical Composition (%):

310:

C:≤0.08 ,Si :≤1.0 ,Mn :≤2.0 ,Cr :24.0~26.0 ,Ni :19.0~21.0,P :≤0.045,S:0.020~0.030

310, 310S and 310H stainless steel plates Equivalent



DIN 1.4845
DIN X12CrNi25-21
DIN X8CrNi25-21
AFNOR Z12CN2520
BS 310S24
UNI X6CrNi2520
SS 2361
UNE F.331
SAE 310S
JIS SUH310
JIS SUS310S
JIS SUS310STP
JIS SUS310STPY
JIS SUS310STB
JIS SUS310SFB
EN X8CrNi25-21
EN 1.4845
UNS S31008
JIS SUS310S



TP 310 / 310S Tainless SteelTechnical datasheet

Chemical Composition

The chemical composition of stainless steel grade 310 MoLN is outlined in the following table.

ElementContent (%)Iron, FeBalanceChromium, Cr24-26Nickel, Ni21-23Molybdenum, Mo2-2.50Manganese, Mn≤ 2Nitrogen, N0.10-0.16Silicon, Si≤ 0.70Phosphorous, P0.025Carbon, C≤ 0.020Sulfur, S≤ 0.010

Mechanical Properties

The mechanical properties of stainless steel grade 310 MoLN are displayed in the following table.

PropertiesMetricImperialTensile strength540-740 MPa78320- 107327 psiProof strength250 MPa36259 psiModulus of elasticity (20°C)195 GPa28282 ksiElongation at break (In 2", 50% cold worked)40%40%Hardness, Brinell9595

Hot Rolled 310S 309S Stainless Steel Bright  Bar For Boiler And Heat Resistant Part



Product Description:


  • Product NameStainless steel barStandardAISI ASTM JIS GB DINGrade200S/300S/400S/600SThickness3mm-20mmWidth25mm-200mmLength2m-6m, or can be customized. 12m Max.Surface Treatment

    Polished, Bright, Hairline, Grinded, Sandblast, Pickled,

    Mill Finish

    TechnologyCold-draw ,Hot-rolledPackageSeaworthy packing or according to the clients' requestApplicationBe used in architecture and engineer structure ,industryTrade TermFOB CIF CFRPaymentT/T L/CLoading PortShanghaiDelivery Time5-30days,mainly depending on quantityReportMaterial report ,Mechanical performance report
  • Materials(Grade):
  • 300series: 301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347,etc
  • 200series:201,202,202cu, 204;
  • 400series:409,409L,410,420,430,431,440;
  • Others:2205,2507,2906,330,660,630,631,17-4ph,17-7 ph,904L,etc
  • Size: 25 x 3mm - 200 x 20mm
  • Length: 2m-6m, or can be customized. 12m Max.
  • Surface Finish: Polished, Bright, Hairline, Grinded, Sandblast, Pickled, Mill Finish


Size of stainless steel flat bar:

 Grade

Hot Rolled

(Black)

Hot Forged

(Black)

Cold Drawn

(Bright)

Smooth Turned

(Bright)

22058mm-200mm150mm-500mm3mm-50mm10mm-300mm904L8mm-200mm150mm-500mm3mm-50mm10mm-300mm3218mm-200mm150mm-500mm3mm-50mm10mm-300mm3048mm-200mm150mm-500mm3mm-50mm10mm-300mm304L8mm-200mm150mm-500mm3mm-50mm10mm-300mm3098mm-200mm150mm-500mm3mm-50mm10mm-300mm310S(2520)8mm-200mm150mm-500mm3mm-50mm10mm-300mm3168mm-200mm150mm-500mm3mm-50mm10mm-300mm316L8mm-200mm150mm-500mm3mm-50mm10mm-300mm3178mm-200mm150mm-500mm3mm-50mm10mm-300mm

Chemical Composition:

 GradeCSiMnPSNiCrMo201≤0 .15≤0 .755. 5-7. 5≤0.06≤ 0.033.5 -5.516 .0 -18.0-202≤0 .15≤l.07.5-10.0≤0.06≤ 0.034.0-6.017.0-19.0-301≤0 .15≤l.0≤2.0≤0.045≤ 0.036.0-8.016.0-18.0-302≤0 .15≤1.0≤2.0≤0.035≤ 0.038.0-10.017.0-19.0-304≤0 .0.08≤1.0≤2.0≤0.045≤ 0.038.0-10.518.0-20.0
