En 10294-1 Grade 20mnv6+Ar Steel Bars
Guangzhou Kingmetal Steel Industry Co., Ltd.- Type：Carbon Steel Bar
- Standard：AISI, ASTM, GB, JIS, DIN, BS
- Technique：Forged
- Application：Structural Steel Bar, Tool Steel Bar, Die Steel Bar
- Surface Treatment：Polished
- Alloy：Alloy
Base Info
- Model NO.：KM-81
- Special Use：Mold Steel, Cold Heading Steel
- Size：130mm-1000mm (Optional)
- Length：2m,3m,5.8m, 6m, 8m or as Required.
- Delivery Time：7-30 Days
- Loading Port：Shanghai
- MOQ：3 Tons
- Certificate：ISO, BV, SGS, Mill Test Certificate
- Packaging Detail：Standard Sea-Worthy Package
- Surface：Bright, Black
- Price Term：Ex-Work, Fob, CFR, CIF, etc.
- Specifications：Flat Bar, Round Bar, Angle Bar, Square Bar
- Transport Package：Standard Sea-Worthy Package
- Specification：130mm-1000mm (optional)
- Trademark：Kingmetal
- Origin：China (Mainland)
- Production Capacity：800tons,Month
Description
Our Steel Grade 20MnV6+AR Round bar conforms to NACE MR0175/ISO 15156
Chemical Composition of CS EN 10294-1 Grade 20MnV6+AR Bars
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.16-0.22 | 0.10-0.50 | 1.30-1.70 | 0.045 | 0.05 | max 0.08 | max 0.40 | max 0.30 | max 0.30 | V0.08-0.15 |
Carbon Steel Grade 20MnV6+AR Bars Mechanical Properties
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 650 | - | - | 17 |
EN 10294-1 20MnV6+AR Hollow Bars Equivalent Properties
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| - | EN 10294-1 Grade 20MnV6+AR | - | - | - | - |
Conditions of Carbon Steel EN 10294-1 20MnV6+AR Flat Bar and Round Bar
| H&T | Hardened and tempered. |
| ANN | Annealed |
| PH | Precipitation hardened. |
Surface finish of EN 10294-1 Grade 20MnV6+AR Hex Bar and Rods
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
