Pre-Painted Color Steel Coil (PPGI/ PPGL)
Guangzhou New Zhonglian Building Materials Co., Ltd.- Standard：ASTM, JIS, GB, AISI, DIN, BS
- Certification：ISO, RoHS, IBR
- Surface Treatment：Coated
- Technique：Cold Rolled
- Application：Flange Plate
- Edge：Slit edge
Base Info
- Model NO.：ZL-PPGI
- Coating Material：PE,Smp,Hdp,PVDF
- Color：Any Color of Ral
- Thickness：0.14mm - 1.50mm
- Standard Width：914,1000,1200,1219,1250mm
- Transport Package：Standard Seaworthy Export Package
- Origin：Tianjin
- Production Capacity：8000tons, Month
Description
Basic Info.
Model NO. ZL-PPGI Coating Material PE/Smp/Hdp/PVDF Color Any Color of Ral Thickness 0.14mm - 1.50mm Standard Width 914/1000/1200/1219/1250mm Transport Package Standard Seaworthy Export Package Origin Tianjin Production Capacity 8000tons/ MonthProduct Description
Pre-painted color steel coil (PPGI/ PPGL)Tole acier prelaquee
Produce to corrugated sheet available
Special thick color coating available
Regular color available: Ocean blue, white-grey, red
- TCT: Total coating thickness
- BMT: Base material thickness
| Standard | ASTM / JIS / BS / DIN / GB / AS |
| Steel Grade | SGCC, SGCH, DX51D, SGH440, G250, G340, G450, G550 |
| Base Material | Galvanized, Galvalume(Alu-zinc), Cold rolled steel |
| Coating Material | PE / SMP / HDP / PVDF |
| Top color coating | 15-45microns (any color of RAL) |
| Back color coating | 5-15microns (off-white) |
| Thickness | 0.14mm-1.50mm (TCT or BMT) |
| Standard width | 914/1000/1200/1219/1250mm, or as required |
| Coil weight | 3-5tons, or as required |
| Coil I.D. | 508mm / 610mm |
