N08810 / 800h Nickel Alloy Pipe
Shanghai Bozhong Metal Group Co., Ltd.- Type：Seamless
- Technique：Cold Rolled
- Material：Stainless Steel
- Surface Treatment：Polished
- Usage：Pipeline Transport, Boiler Pipe, Oil,Gas Drilling, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose
- Section Shape：Round
Base Info
- Model NO.：Pipe
- Pipe：Pipe
- Transport Package：Fumigated Wooden Box
- Specification：diameter 10 to 200mm
- Trademark：Bao Steel
- Origin：China
- HS Code：7304419000
- Production Capacity：5000mt,Mt
Description
Introduction
Super alloy VLX800H is a slightly modified version of Incoloy 800 with the 800H grade possessing higher creep and rupture strength. This modification is possible because of the closely controlled carbon content and modified heat treatment.
The following sections will discuss in detail about super alloy VLX800H.
Chemical Composition
The chemical composition of super alloy VLX800H is outlined in the following table.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 30 - 35 |
| Chromium, Cr | 19 - 23 |
| Manganese, Mn | 1.5 max |
| Silicon, Si | 1 max |
| Copper, Cu | 0.75 max |
| Aluminum, Al | 0.15 - 0.6 |
| Titanium, Ti | 0.15 - 0.6 |
| Carbon, C | 0.05 - 0.1 |
| Sulfur, S | 0.015 max |
| Iron, Fe | Remainder |
Physical Properties
The physical properties of super alloy VLX800H are tabulated below.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.9 g/cm3 | 0.287 lb/in3 |
| Melting point | 1371°C | 2500°F |
Other Designations
Equivalent materials to super alloy VLX800H are provided below:
Bar & Rod
Rolled barΦ5-45mm,Length≤1500mm
Polished Bar(circle,Square)
Solution annealing,descaling
Forged barΦ26-245mm,Length≤4000mm
Weld tube
Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm
Base on your requirement
Use for PHE
Seamless Tube
Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm
Base on your requirement
Use for PHE
Wire
Outer diameterΦ0.1-13mm
Base on your requirement
Ni & Ni alloy, Ti & Ti alloy
Forged piece
roundness and square alloy
Base on your requirement
Steel, Alloy
Flangs
All kinds of Flangs
Base on your requirement
Steel, Alloy
Welding Material
Coil wire Φ0.90mm/1.2mm/1.6mm
Base on your requirement
Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France.
Straight WireΦ1.2mm/1.6mm/2.4mm/3.2mm/4.0mm
Welding rodΦ2.4mm/3.2mm/4.0mm
Tube
Elbow, three links, four links, different diameter size
Base on your requirement
Ni & Ni alloy, Ti & Ti alloy
Explosive bonded laminate
Raw Sheet Thickness≥2mm
Base on your requirement
Ni & Ni alloy, Ti & Ti alloy
