• Model NO.：TP316L TP347 TP310
• Transport Package：Bundle, Wooden Case
• Trademark：C&N
• Origin：China
• Production Capacity：100ton,Month

                    Chemical composition (%) of TP304
C
Si
Mn
P
S
Ni
Cr

Mo
V
≤0.08
≤0.75
≤2.00
≤0.045
≤0.030
8.0-10
18-20

0.15-0.30
0
                 Mechanical properties of TP304
Tensile strength/MPa
Yield strength/MPa
Elongation/(%)
Reduction/(%)
Impact/J
Hardness/HB

≥515
≥205
≥40
/
/
≤217

Material
TP304/304L, 316/316L, 310S, 317L, 321, 347H,etc.
S31803, 32750, etc.
2. Standard
ASTM, ASME, DIN, EN, ISO,JIS, GOST, etc.
3. Type
Seamless
4. Size range
OD: from 4mm to 914.4mm
WT: from 0.5mm to 45mm (Schedule from 5S to XXS)
Length: fix length or un-fix length, Max 30meters
5. Produce process
Pilgering and cold drawn
6. Surface process
Pickling and annealing
AP tube
BA tube
7. Marking
JW, GRADE, seamless, STANDARD, SIZE, HT NO.
8. Package
Bundles with waterproof cloth outside.
or plywood box.
9. Min order quantity
500 KG
10. Sample
Yes
11. OEM accepted
Yes
12. Production capacity
1,000 tons per month
13. Payment term
T/T or L/C.
14. Certificate
ISO 9001, PED
15. Third party ertificate
BV, LR, SGS, TUV, CCS, ABS, etc.

Equipments for seamless steel pipe:


Photos of equipments for TP304 stainless steel pipe.


Packing and delivery:
We normally has 2 type of package, one is wooden cases and the other is easier one. We can also pack them as customers' requests. We are sure that all is safe enough during the transportation.


Photos of package for TP304 stainless steel pipe.

Application for TP304 stainless steel pipe:
Our products are widely used in petroleum, chemical, paper, machinery, medicinal and food industry.

Photos of application for TP304 stainless steel pipe
