Cold Heading Steel Special Use and Construction, Rope, Fencing, Packing, Netting Application Galvanized Steel Wire
ZHEJIANG WANSHENG YUNHE STEEL CABLE CO., LTD.- Certification：ISO, CCC, CE
- Surface：Smooth
- Technique：Galvanized
- Application：Rope, Packaging, Netting, Manufacturing, Fencing, Construction, Steel Cable
- Alloy or Not：Non-alloy
- Standard：BS, JIS, GB, ASTM, DIN, AISI
Base Info
- Samples：Free Samples
- MOQ：1 Ton
- Transport Package：Coil Packing, Z2 Packing, Wooden Reel Packing
- Specification：0.3-5.0mm
- Trademark：yunhe
- Origin：China
- HS Code：7217100000
- Production Capacity：12000 Per Month
Description
Zinc-coated steel wire for stranded conductors(Strength General) diameter mm Tensile Strebgth
No Less Than Tensile Strength
No Less Than LD=250mm Elongation
Noless Than% Number Of Twist/360
No less Than Diameter Of Core ROD
FOR Wrap Test(times) (A)General strength >1.24-2.25 1340 1170 3 18 1D >2.25-2.75 1310 1140 3 16 1D >2.75-3.0 1310 1140 3.5 16 1D >3.0-3.5 1290 1100 3.5 14 1D >3.5-4.25 1290 1100 4 12 1D >4.25-4.75 1290 1100 4 12 1D >4.75-5.5 1290 1100 4 12 1D (A)Higher strength >1.24-2.25 1450 1310 2.5 16 3D >2.25-2.75 1410 1280 2.5 16 3D >2.75-3.0 1410 1280 3 16 4D >3.0-3.5 1410 1240 3 14 4D >3.5-4.25 1380 1170 3 12 4D >4.25-4.75 1380 1170 3 12 4D Extra Higher Strength >1.24-2.25 1620 1450 2 14 3D >2.25-2.75 1590 1410 2 14 3D >2.75-3.0 1590 1410 2.5 12 4D >3.0-3.5 1550 1380 2.5 12 4D >3.5-4.25 1520 1340 2.5 10 4D >4.25-4.75 1520 1340 2.5 10 4D
No Less Than
No Less Than
Noless Than%
No less Than
FOR Wrap Test(times)
| Spring steel wire | Diameter | Tensile Strength | Packing |
| DIN | 0.4-2.3mm | Grade A or B | Spool,Coil,Z2 |
| JIS 3521 | 0.4-2.3mm | SW-A,SW-B,SW-C | Spool,Coil,Z2 |
| EN-10270-1 | 0.4-2.3mm | SL,SM,SH | Spool,Coil,Z2 |
| EN10264-2 | 0.4-2.3mm | 1370-1960 | Spool,Coil,Z2 |
| ISO 2232 | 0.4-2.3mm | 1370-1960 | Spool,Coil,Z2 |
| DIN 2078 | 0.4-2.3mm | 1370-1960 | Spool,Coil,Z2 |
| Optical cable steel wire | Diameter | Tensile Strength | Packing |
| Galvanized wire | 0.4-2.3mm | 1320-1960 | Spool,Coil,Z2 |
